MUGA (Multi Use Games Area) Construction

MUGA surfaces | Sovereign Sports
A MUGA (or Multi Use Games Area) is a specially designed area for use with a variety of different sports. For example, tennis, netball, basket ball, five-a-side football. Depending on the sports to be played, the surface and surround fencing will differ. For example on a tennis court, a netball court or basketball sports pitch, a chain link fence would be suitable. If five-a-side football / hockey were to be played then a synthetic surface would be advisable, along with more robust perimeter fencing, such as a sports rebound panel system.

MUGA surfaces | Sovereign SportsThere are a number of stages in the construction of a MUGA pitch prior to the installation of the synthetic grass surface.

The depth of stone and the drainage required is dependent upon the site conditions and it is recommended that an independent site investigation is carried out prior to the commencement of any works. The depth of stone that is recommended in accordance with SAPCA (the Sport & Play Contractors Association) is usually a minimum of 250mm.

Pitches are usually constructed on a stone (dynamic) or macadam (engineered) base.

Macadam Engineered Base

If an engineered base is chosen in the construction of a synthetic pitch, a macadam base will be laid over the base stone. A macadam base can consist of either one or two layers of macadam depending upon the budget available. A second layer of macadam will create a more structurally sound base, prior to the carpet going down. If the finish surface selected is open textured macadam, then a 2 layer system would be advisable

The structure of an Macadam Engineered Base:

MUGA surfaces | Sovereign Sports

Dynamic Stone Base

A Dynamic stone base is made up of aggregate layers. Each stone layer is laid and fully consolidated to ensure no movement or subsiding ever occurs in the future. The top layer is usually laid by hand, using screed rails, which have been levelled using a dual plane laser.

A Dynamic stone base was originally considered the best foundation on which to construct a sports facility, as an unbound stone allows the shockwaves from impact to disperse between the stone aggregate, making it more appealing to the end user by reducing the likelihood of impact-related injuries. Another benefit of installing this type of construction is that it is more economical.

The Structure of a Dynamic Stone Base:

MUGA surfaces | Sovereign Sports
MUGA surfaces | Sovereign Sports
muga surfaces - Sovereign Sports

We offer MUGA construction services across the UK, including: East Sussex, West Sussex, Hertfordshire and Essex. We have constructed multi-use games areas in major towns and cities across the southeast, including London and Tunbridge Wells.

For more information on our services contact us today by filling in the form below.

Rickmansworth Playing Fields Case Study

Site Survey
Piercing of surface
Removal of old tennis sockets
Preparation work to perimeter of courts
Installation of new kerbing
New Stone
Concrete ringbeam poured to secure new kerbs
Gate Adaption, to accomodate new court height
Laser levelling of new stone layer
Wearing course macadam laid
New macadam Down
Colour spraying
Completed

Surfaces

Sovereign Sports offer a range of synthetic surfaces suitable for Multi use play. Ranging from Matchplay2, which is a 6mm sand dressed synthetic surface through to Conqueror 60 MF 3rd Generation 60 mm sand and rubber infill, ideal for five-side football.

more

Fencing

Our company provides two systems as standard, tubular or angle iron powder coated in either green or black, installed around the perimeter of the court to a height of a 2.75m (9ft). There is a vast array of fencing systems on the market today, so if you have something in mind please don’t hesitate to contact us.

more

Maintenance

All surfaces need regular maintenance to retain good condition, whether it is porous macadam, synthetic clay, synthetic grass.
Every surface should be swept clean and all leaves, pine needles, detritus and rubbish should be removed on a weekly basis

more

Floodlighting

floodlightsSovereign Sports are able to offer 2 types of lighting system, Static or Retractable. Our retractable system is aimed more at the private client, being less obtrusive than the full size static option. The static system we offer complies with SAPCA and LTA recommendations and is the preferred choice for clubs and schools.

more

Associated Work

Along with our main concern, being the construction of tennis courts and sports surfaces. We also carry out a wide range of associated works and optional extras which include double edge perimeters, personalised fencing posts, practice walls, retaining walls, paths, patio areas, steps and landscaping to the surround of the court.
